NN Conveyor Belt (Nylon Conveyor Belt)
Nylon is characterized by thin belt carcass, high strength, shock resistance , good performance, large layer to layer adhesion, excellent flexibility and long service time, applicable to conveying of the heavy product at high speed in middle and short distance.
Specification and techical data of multi-ply nylon conveyor belt:
Fabric type
|
Fabric Structure |
Fabric specs |
Ply thickness
(mm/P)
|
(N/mm) Strength series |
(mm)Cover thickness |
Widtth mm |
Length m |
||||||
Warp |
Weft |
2py |
3ply |
4 ply |
5 ply |
6 ply |
Upper |
Lower |
|||||
Nylon (NN) |
Nylon (N) |
Nylon (N) |
NN-100 |
1.0 |
200 |
300 |
400 |
500 |
600 |
1.5-8 |
0-4.5 |
400-2500 |
<=500 |
NN-125 |
1.0 |
250 |
375 |
500 |
625 |
750 |
|||||||
NN-150 |
1.1 |
300 |
450 |
600 |
750 |
900 |
|||||||
NN-200 |
1.2 |
400 |
600 |
800 |
1000 |
1200 |
500-2500 |
||||||
NN-250 |
1.4 |
500 |
750 |
1000 |
1250 |
1500 |
|||||||
NN-300 |
1.6 |
- |
900 |
1200 |
1500 |
1800 |
|||||||
NN-350 |
1.7 |
- |
1050 |
1400 |
1750 |
2100 |
800-2500 |
||||||
NN-400 |
1.9 |
- |
- |
1600 |
2000 |
2400 |
|||||||
NN-500 |
2.1 |
- |
- |
2000 |
2500 |
3000 |
Adhesion and elongation of the belt:
Belt
carcass
|
Adhesive strdngth |
Elongation |
|||
Between
plies
N/mm
|
N/mmBetween rubber and carcass |
Longitudinal
elongation at break
%>=
|
Longitudinal
elongation at reference load
10%<=
|
||
Rubber thickness
<=1.5mm
|
Rubber thickness
>1.5mm
|
||||
Nylon canvas |
>=5.5 |
>=4.5 |
>=4.5 |
10 |
2.5 |
