Product Catalog
Rubber Sheet

NR/SBR Rubber Sheet

Width : 2000mm(max)

•Length : Any length

•Thickness : From 1.2mm to 50 mm

•Standard Color : Black Green Red

•Hardness:Shore A 45-85

•Tensile Strength:2.5mpa-25mpa

•Elongation: ≥180%

*Two sides can be smooth, or fabric pattern.

* Fabric insertion available for request.

Rubber Sheet with Insertion

•Width 2000mm(max)

•Length : Any length

•Thickness : From 1.8mm to 80 mm

•Standard Color : Black Green Red

•Hardness:Shore A 45-85

•Tensile Strength:2.5-25mpa

•Elongation: ≥180%

CR/NBR Rubber Sheet

Width : 2000mm(max)

•Length : Any length

•Thickness : From 1.2mm to 50 mm

•Standard Color : Black Green Red

•Hardness:Shore A 45-85

•Tensile Strength:2.5mpa-25mpa

•Elongation: ≥180%

*Two sides can be smooth, or fabric pattern.

* Fabric insertion available for request.


Pure natural rubber Sheet

Quality: Industrial grade, food grade
Color: Black, white, brown, beige, red, green etc.
Surface: Smooth/smooth, smooth/impression fabric, double impression fabric
Tensile strength: 2-22Mpa(maximum 3142PSI)
Hardness: 40, 50, 60, 70, 80+/-5shore A
Elongation: 170%-760%
Density: 1.05-1.70g/cm3
Working temperature: -35° C - +85° C
Thickness: 1.0-50.0mm
Width: 0.1-2.0m
Length: 1.0-20m
Insertion: Reinforce to insert 1-3PLY fabric

Silicon Rubber Sheet

material: 100% virgin silicone rubber from Germany or China
quality: high tear resistant or middle tear resistant
color: translucent, dark red, black, milk white, grey, blue etc.
surface: smooth/smooth, smooth/impression fabric, smooth/sanded
insertion: reinforced and insert 1 PLY fabric
tensile strength: 7-12Mpa
hardness: 15, 20, 30, 40, 50, 60, 70, 80+/-5shore A
elongation: 350%-760%
density: 1.25-1.30g/cm3
tear strength: 26-42N/mm
working temperature: -60°C - +260°C(moment maximum 300°C)
thickness: 0.1-30mm
width: 0.5-3.8m
length: 1-50m
grade: industrial grade, food grade
